6000 KW Generator Load Bank 11 KV With 86～106 KPa Atmospheric Pressure

Name: 6000 KW Generator Load Bank 11 KV With 86106 KPa Atmospheric Pressure
Brand: KAIXIANG
Price: 1 USD

Brand Name : KAIXIANG

Model Number : AC11kV-6000kW

Certification : ISO9001

Place of Origin : HEBEI CHINA

MOQ : ONE SET

Price : negotiable

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 20 SETS ONE MONTH

Delivery Time : ONE MONTH AFTER GET DEPOSIT

Packaging Details : WOODEN CASE

Rated power : 6000 KW

Display Precision : 0.5 class

Load Resolution : 250.250.500.1000.2000.2000KW

Rating Voltage/Frequency : 11000V/50Hz, 3 phase 3 wire

Atmospheric Pressure : 86～106 kPa

Fuse : DELIXI

Contact Now

Testing On Generator Sets 11kV 6000kW Dummy Generator Load Bank

Product Description

1. This system, which is of independent research and development of electricity load test equipment by our technology, combining dry load module with the automatic measurement and control module, can accurately detect all kinds of generator output power and load capacity, full load and overload test.

2. The system can be used with a computer to realize the intelligent control, automatically completing the special test to all electrical parameters of generating set and generating tables, graphs, and supporting the print, comprehensively from the cumbersome manual operation to provide scientific and efficient detection means for the power generating sets.

Technical Parameter

Rating Voltage/Frequency	11000V/50Hz, 3 phase 3 wire
Rated power	Resistive:6000kw
Load Resolution	250.250.500.1000.2000.2000KW
PF(Power Factor)	1
Load Tolerance (each step)	±5%
Load Tolerance(overall)	±3%
Display Precision	0.5 class
Control Power	415VAC/50Hz,
Weight	About 16000kgs/set
Size	1219223502591mm
Transportation	Hoisting, there are lifting lug in top of casing
Casing Color	Grey(RAL7035)
Ambient Temperature	-10℃～+50℃
Relative Humidity	≤95%
Altitude	≤2500 meter

Product Advantages

1. Cooperate with many well-known enterprise, offer OEM and ODM service to world famous brands.

2. Certified with China Classification Society (CCS) and ISO9001:2008 Quality Certificate.

3. Triumph Load is the first brand in the emergency power supply test & maintenance industry in China

Application

Manufacturers of standby power generators commonly use load banks to test and tune newly assembled units. When the generator has been set up in a test cell within the factory, a test engineer uses the load bank to apply a discrete, selectable electrical load to the generator and measure the response stability and endurance. During this process, the test engineer calibrates and adjusts the generator performance to ensure it meets the intended product specifications and tolerances.

6000 KW Generator Load Bank 11 KV With 86～106 KPa Atmospheric Pressure

Product Tags:

dummy generator load bank

dc load bank

China 6000 KW Generator Load Bank 11 KV With 86～106 KPa Atmospheric Pressure wholesale

6000 KW Generator Load Bank 11 KV With 86～106 KPa Atmospheric Pressure Images
